Real-Life Examples

Understanding CPU profiling is easiest when you see it applied to real-world problems. This article walks through practical examples, starting with profiling a simple script and progressing to more complex builds that involve multiple threads and processes. You will see what current tools make possible, where their limitations appear, and find strategies to approach profiling with greater confidence in your own projects.

Quickly CPU profile your script

The following example demonstrates how to CPU profile a Node.js script using the --cpu-prof flag. This offers a quick way to get an overview of its performance.

exmpl-script.js

console.log('exmpl-script.js PID', process.pid);
let sum = 0;
for (let i = 0; i < 10000000; i++) {
  sum += Math.sqrt(i);
}
process.exit(0);

Command:

node --cpu-prof exmpl-script.js
# This will not work as the arguments may not be passed down
# node ./exmpl-script.js --cpu-prof

This command will CPU profile the exmpl-script.js script and generate a profile file in the current working directory. The filename will follow the pattern CPU.<timestamp>.<pid>.<tid>.<seq>.cpuprofile:

Output:

/root
   └─ CPU...0.001.cpuprofile

CPU profile multiple threads grouped in a folder

When a program creates multiple worker threads, you can use the --cpu-prof flag to profile each of them. The example below shows how to group multiple processes into a folder, keeping the measurements for different processes separate.

exmpl-create-threads.js

import { Worker, threadId } from 'worker_threads';

const workerCodeESM = `import { threadId as t } from 'worker_threads';
console.log('Worker PID:', process.pid, 'TID:', t);`;
const workerDataURLString =
  'data:text/javascript,' + encodeURIComponent(workerCodeESM);

new Worker(new URL(workerDataURLString));
new Worker(new URL(workerDataURLString));
console.log('Main PID:', process.pid, 'TID:', threadId);

Command:

node --cpu-prof --cpu-prof-dir=./cpu-prof-threads ./exmpl-create-threads.js

Output:

root/
 └─ cpu-prof-threads/
    ├─ CPU...0.001.cpuprofile
    ├─ CPU...1.002.cpuprofile
    └─ CPU...2.003.cpuprofile

For a more real-life example, consider profiling the Angular framework's build process, which makes extensive use of worker threads to distribute work across its various build steps.

Command:

node --cpu-prof --cpu-prof-dir=./angular-build node_modules/.bin/ng build

Output:

/root
   ├─ CPU...0.001.cpuprofile
   ├─ ...
   └─ CPU...32.032.cpuprofile

32 .cpuprofile files are generated, one for each worker thread. HAHA! Good luck analyzing that!

In the earlier examples, we could use relative paths because the CWD stayed the same. In practice, this is often not the case, and your files may end up in different folders depending on the current working directory.

CPU profile multiple processes grouped in a folder

You can profile multiple processes and store their results together in a single folder.

exmpl-spawn-processes.js

import { spawn } from 'node:child_process';
import { threadId as t } from 'node:worker_threads';
import { join, dirname } from 'node:path';
import { fileURLToPath } from 'node:url';
import { mkdirSync } from 'node:fs';

const __filename = fileURLToPath(import.meta.url);
const __dirname = dirname(__filename);
// normally this folders exist as the location of the executed script is in that folder.
mkdirSync(join(process.cwd(), 'child-process-1'), { recursive: true });
mkdirSync(join(process.cwd(), 'child-process-2'), { recursive: true });

const childScriptPath = join(__dirname, 'exmpl-script.js');

spawn(process.execPath, [childScriptPath], {
  stdio: 'inherit',
  cwd: join(process.cwd(), 'child-process-1'),
});
spawn(process.execPath, [childScriptPath], {
  stdio: 'inherit',
  cwd: join(process.cwd(), 'child-process-2'),
});

console.log('Parent PID:', process.pid, 'TID:', t);

When doing this, make sure the output directory specified by --cpu-prof-dir is set to an absolute path.

Command:

NODE_OPTIONS="--cpu-prof --cpu-prof-dir=/Users/user/workspace/cpu-prof-processes"
node ./exmpl-spawn-processes.js

# This will not work as the --cpu-prof params are not passed
# node --cpu-prof --cpu-prof-dir=./cpu-prof-processes ./exmpl-spawn-processes.js

# This will not work as the directory is relative to the CWD, which is not the same
as the script location.
# NODE_OPTIONS="--cpu-prof --cpu-prof-dir=./cpu-prof-processes"
node ./exmpl-spawn-processes.js

Note: The NODE_OPTIONS environment variable is required to apply CPU profiling options to all child processes. This ensures each spawned process generates its own .cpuprofile file in the specified directory. Using only --cpu-prof-dir as a command-ine argument will not work, as the --cpu-prof flag may not be passed to child processes automatically.

Output:

/root
   ├─ CPU..1.0.001.cpuprofile
   ├─ CPU..2.0.002.cpuprofile
   └─ CPU..3.0.002.cpuprofile

One practical real-world example is Nx for managing smart repositories. Building all projects in a monorepo with Nx spawns multiple processes for each project, along with potential threads depending on the build tool in use.

Command:

NODE_OPTIONS="--cpu-prof --cpu-prof-dir=/Users/user/workspace/cpu-prof-nx-build-many"
nx run-many -t build --skip-nx-cache

Output:

/root
   ├─ CPU..1.0.001.cpuprofile # root process
   ├─ CPU..2.0.002.cpuprofile # child_process.spawn
   ...
   ├─ CPU..7.0.007.cpuprofile # child_process.spawn
   ├─ CPU..7.1.008.cpuprofile # worker_threads.Worker
   ├─ CPU..7.2.009.cpuprofile # worker_threads.Worker
   ...
   └─ CPU..9.0.011.cpuprofile # child_process.spawn

In practice, you would rarely profile that many processes at once. For example, Nx's TUI already provides a comprehensive overview of build times, and most other solutions include similar rough stats. From there, you can focus on the slowest part of the process and profile it in detail.

Understanding multiple CPU profiles created by a single measurement

Currently, there is no officially supported tool for visualizing multiple CPU profiles generated during a single measurement. The most we can do with the default tools is apply a few best practices and follow established processes.

  • Less is more

    Don't waste time creating 100 profiles that are hard to make sense of. Instead, run a measurement, open a few profiles, and work through them to form hypotheses. Once you have more clues, plan and run targeted measurements.

  • Rename your profiles

    While building your understanding, it helps to rename the original profile file names to something more meaningful that you can remember and get back to later.

  • Isolate your measures

    After you have identified the culprit, isolate the measurement to only what you need. For example, if you find a slow function, run just that function with --eval or in a standalone microbenchmark.

    node --cpu-prof -e "
const { slowFunction } = require('./slow-module.js');
slowFunction();
"

  • Focus on quick wins and document your findings

    Prioritize issues you understand, that have high impact, and are easy to fix. Avoid spending time on unclear, low-impact, or hard-to-guess problems.

  • Use the right tools

    While there is no official tool for visualizing multiple CPU profiles, you can use @push-based/cpu-prof. It is a CLI that helps create and merge multiple CPU profiles into a single profile that the Chrome DevTools Performance Panel can read.

Conclusion

Exploring practical CPU profiling examples is one of the most effective ways to improve your performance analysis skills. Even though today’s tools have their limits, an organized and focused approach makes it much easier to cut through complexity and pinpoint what matters most. The profiling scenarios discussed above provide a strong foundation to start profiling your own projects and the confidence to keep exploring and optimizing for even better performance.
